SKU:
BDW-10062
Availability:
Sorry, these are no longer available from Bull Dog Winches
9800lb Trailer Winch w/ Synthetic Rope & Hawse Fairlead Bulldog Winch - 10062
Features-
- Power Load In and Out
- Automatic Load Holding Brake
- Free-spooling Clutch For Quick Wire Rope Deployment
- Low Profile
- Heavy Duty Truck Winch Chassis & Gear Box
- Narrow Drum and Rope Tension For Easy Rope Handling
- Power Unit Mounted On End Of Motor
- 2 Year Limited Warranty
Specifications-
- Motor: 12v DC 5.8hp 4.2kw
- Rated Line Pull: 9,800lbs (5443kgs)
- Control: Remote Handheld with 20' (6.1m) Lead
- Gear Train: 3 Stage Planetary
- Gear Ratio: 265:1
- Clutch: Freespool
- Brake: Automatic Load Hold
- Drum Diameter xL: 2.5"x2.7" (63.5mm x 70mm)
- Battery Leads: 6ft (1.83m)
- Overall Dimensions: 21.5" x 7.32" x 7.79" (545 x 186 x 198mm)
- Winch Mounting Bolt Pattern: 4.5" x 6.67" (114 x 167mm)
- Plate Mounting Bolt Pattern: 14.52" x 5.8" (369 x 148mm)
